| PACKING MATERIAL | LAMINATED FILM ROLL 2/3/4 LAYER |
| PACKING RANGE | 10 GM TO 1000 GM |
| MACHINE SPEED | 60 PPM |
| MAX ROLL WIDTH | 450 MM |
| MAXIMUM POUCH LENGTH | 290MM |
| FILM DRAW MECHANISM | SERVO/GEARED MOTOR |
| HORIZONTAL AND VERTICAL SEAL | PNEUMATIC |
| VOLUMETRIC CUP FILLER | 6 STATION-8 STATION |
| TYPES OF SEALING | CENTRAL SEAL |
| POWER CONSUMPTION | 6 KW, 3 PHASE |
| AIR CONSUMPTION | 6 CFM@ 7 KG/ SQ CM |
| MACHINE DIMENSION | 1500 LX 3600 W X 4200 H ( LXWX H) MM |
| MACHINE WEIGHT | 600 KGS |
| MACHINE STRUCTURE | MS POWDER COATED |
| CONTACT PARTS | SS-304/SS-316 ( FOOD GRADE) |
| OPTIONAL ATTACHMENTS | FILLING ACCURACY |
|---|---|
| HOT INK COADING / PINNING/SIDE GUSSETTING | NITROGEN FLUSHING |
| FILLING ACCURACY +/- 1% | LAMINATE REJECTION +/- 1% |
